KONE Bed elevator

The KONE Bed elevator is designed especially for hospitals.

Two hospital personnel in elevator
Contact us

Send us a message and we'll get back to you shortly

What are you interested in?

KONE Bed Elevator

Safe, smooth and reliable elevator designed especially for hospitals, with a solid set of features for optimum performance in the highly demanding environment of patient transportation. Machine room-less/ small machine room elevator for hospitals.

Speed
1.75 m/s
Max. travel
75 m
Max. load
1768 kg
Max. persons
Up to 26
Max. group size
4
Signalization
KDS90; KDS93; KDS96
Hospital elevator with people and patient in bed

Design

  • Specialized Car design to accommodate the bed and medical equipment, with wide opening doors and deeper car
  • Smooth entry and exit: precise leveling for easy entry of wheelchairs, beds and patients
  • Priority / emergency calls for immediate availability during emergency situations
  • Quiet operation to prevent disturbance to patients in wards adjacent to the elevator shaft
  • Hygiene: easy to use, durable wall and floor materials
  • Clear signalization for easy access and use

Related topics

  • image

    KONE Escalators

    Explore KONE escalators, moving walkways, and autowalks for commercial buildings, retail, airports, and transit hubs in India. Discover smart, energy-efficient people flow solutions.
  • image

    Maintenance and service

    KONE lift & escalator maintenance services deliver maintenance across the entire portfolio, ensuring safe and reliable operations with predictive maintenance.
  • image

    Advanced People Flow Solutions

    Enhance building access and people flow with KONE Advanced People Flow Solutions, designed for smooth, secure, and efficient movement.

Elevator solutions

Product
Description + segment
Machine room
Max. speed
Max. travel
Max. load/persons
KONE A MonoSpace®Machine-room-less elevators for low-rise residential buildingsNo
0.63 m/s20 m
544 kg / up to 8 persons
KONE A MiniSpace™
Compact Machine-room elevators for low-rise residential buildings
Yes
0.63 m/s
30 m
544 kg / up to 8 persons
KONE I MonoSpace®
Modern Elevators for Residential & Commercial buildings
No
1.75 m/s90 m
1020 kg / up to 15 persons
KONE I MiniSpace™Modern Elevators for Residential & Commercial buildingsYes
1.75 m/s100 m1020 kg / up to 15 persons
KONE U MonoSpace®Machine-room-less elevators for mid range buildings
No
2.5 m/s90 m
1786 kg / up to 26 persons
KONE U MiniSpace™Compact machine room elevators for mid range buildings
Yes
2.5 m/s135 m
1786 kg / up to 26 persons
KONE Highrise MiniSpace™High-speed elevator for high-rise buildingsYes
4 m/s180 m
1600 kg / up to 24 persons
KONE TranSys®Adaptable passenger and goods elevator solution for public transport, retail, hospital buildings
No
1.0 m/s
40 m
4000kg / up to 53 persons
KONE Bed elevator
Elevator designed especially for hospitals
Yes & No
1.75 m/s
75 m
1768 kg / up to 26 persons

References

  • HUS Helsinki University Hospital

    HUS Helsinki University Hospital

    Discover how HUS Helsinki University Hospital keeps critical healthcare services moving with KONE’s maintenance expertise and digital solutions, ensuring high elevator availability across one of Finland’s largest hospital networks.
  • Royal Children's Hospital

    Royal Children's Hospital

    Discover how KONE supported Royal Children’s Hospital Melbourne with elevator solutions that enable efficient patient transport, reliable people flow, and sustainable building operations.
