From standard commercial freight to heavy industrial loads, KONE Freight Elevators are available in configurations ranging from 4,000 lbs to 15,000 lbs capacity. Every elevator is specified for its application – the right platform size, door configuration, and load rating for your facility, the first time.
Core benefits
Available in three configurations to match your load requirements, building layout, and operational goals. Full platform dimensions, hoistway requirements, and door specifications are available in the planning guide.
A practical, efficient freight elevator for standard commercial applications in warehouses and mid-rise commercial buildings.
A heavy-duty freight elevator built for continuous industrial use in manufacturing and distribution environments.
The highest-capacity freight elevator in the range, designed for large logistics and industrial facilities with demanding throughput requirements.
Lifecycle value
Continuously optimize the logistics flow and improve operations in your building with the assistance of an experienced partner. We can help you make your building smarter and more efficient with valuable insights based on a holistic view of end-user behavior and goods flow.
Our team will work with you to identify the right configuration for your load requirements, building layout, and operational goals. Fill in the form and one of our specialists will be in touch.
See how we've partnered with customers, helping them plan, design, and install solutions that perfectly meet their unique needs.
No results found
KONE Freight Elevators are purpose-built industrial elevator solutions engineered from the ground up for goods transport – not adapted from passenger elevator designs. Available in three models (MonoSpace 700 DX, MonoSpace MRL Freight DX, and MiniSpace Freight DX), they serve a range of applications from standard commercial warehouses to large-scale industrial and distribution facilities, with capacities from 4,000 to 15,000 lbs.
KONE Freight Elevators are available in three capacity ranges: the MonoSpace 700 DX handles 4,000–5,000 lbs for standard commercial freight; the MonoSpace MRL Freight DX handles 6,000–10,000 lbs for continuous heavy industrial use; and the MiniSpace Freight DX handles 8,000–15,000 lbs for the most demanding logistics and industrial throughput requirements.
KONE Freight Elevators are designed to meet all ASME A17.1 freight loading classifications: Class A (general freight), Class B (motor vehicles), Class C1 (industrial trucks – standard use), Class C2 (industrial trucks – temporary overload), and Class C3 (heavy industrial loading where vehicles do not travel with the load). Talk to your local KONE sales representative to confirm which classes apply to your specific model and project requirements.
The three models serve different scales of freight operation. The MonoSpace 700 DX is the entry-level option for standard commercial applications such as warehouses and mid-rise commercial buildings (4,000–5,000 lbs). The MonoSpace MRL Freight DX is a heavy-duty solution for continuous industrial use in manufacturing and distribution environments (6,000–10,000 lbs). The MiniSpace Freight DX is the highest-capacity option for large logistics and industrial facilities with demanding throughput requirements (8,000–15,000 lbs).
Yes. KONE Freight Elevators are designed to comply with ASME A17.1, the Safety Code for Elevators and Escalators. This includes compliance with accessibility, vandal-resistance, and fire service operation requirements. KONE manages the full project from planning to installation, including support for any required third-party inspections.
Yes. KONE Freight Elevators are suitable for full replacement projects, providing a straightforward way to bring aging freight elevators up to modern standards. Improvements include accurate leveling, proper lighting, connectivity, and compliance with the latest safety codes. KONE manages the entire replacement project from planning through installation and handover.
